Outstanding Products Make You Stand Out
Each SMT pick and place machine is guaranteed to boost your PCB assembly business thanks to the number of qualities listed below.
- ⚡Precise Placement: The accuracy of our SMT pick and place machines can achieve a level of precision that surpasses any human pick and place handling.
- 🔥High Flexibility: All SMT pick and place machines are easy to program for various PCB boards with different dimensions, production requirements, and specifications.
- 🧱Ease of Use: With the user-friendly aspect of our SMT pick and place machines, they can be incorporated into your production floor with the minimum training requirement.
- 🧩Low Maintenance: The cutting-edge technology of our SMT pick and place machines requires minimal maintenance, helping you reduce cost while increasing productivity.
<h3>🔶 F-900 High-Speed Dispensing Machine Specifications</h3>
| Specifications | |
| XY Travel | 420 × 680 mm |
| Effective Dispensing Area | 400 × 430 mm |
| XY Acceleration | 3 G |
| XY Maximum Speed | 2000 mm/s |
| XY Repeatability | ±0.015 mm |
| XY Resolution | 0.001 mm |
| Z Travel | 60 mm |
| Z Acceleration | 0.75 G |
| Z Maximum Speed | 500 mm/s |
| Z Repeatability | ±0.01 mm |
| Electronic Scale Resolution | 0.1 mg |
| Bottom Heating Mode | Vacuum / Hot Air (Optional) |
| Temperature Control Accuracy | Within ±0.5 °C |
| Conveyor Stations | 1–3 Stations (Optional) |
| Conveyor Width | 30–400 mm |
| Conveyor Mode | Step Conveyor |
| Conveyor Belt | Synchronous Timing Belt |
| Cleaning Method | Vacuum / Tape Wiping (Optional) |
| Vision Lighting | Direct / Diffuse / Oblique Multi-color Lighting (Optional) |
