Samsung SM421S High-Speed Chip Mounter
Samsung SM421S High-Speed Chip Mounter - Image 2

Samsung SM421S High-Speed Chip Mounter

Description

● The Samsung SM421S High-Speed SMT Pick and Place Machine for Precision PCB Assembly is engineered to deliver exceptional placement accuracy, fast throughput, and stable operation for modern electronics manufacturing.

● Equipped with multi-gantry placement heads, on-the-fly vision alignment, and intelligent feeder control, the SM421S ensures consistent, high-quality placement for components ranging from ultra-small 01005 chips to large IC packages.

● Its rigid mechanical platform and modular production flexibility make it suitable for both high-mix and high-volume SMT environments.

● With advanced features such as automatic nozzle calibration, real-time process monitoring, and optimized placement algorithms, the SM421S delivers long-term reliability and superior yield performance.

● Fully CE and RoHS compliant, the Samsung SM421S integrates smoothly into automated SMT lines and provides manufacturers with a stable, efficient, and scalable solution for precision PCB assembly.

  • Brand: Samsung
  • Model: SM421S
Category:

Outstanding Products Make You Stand Out

Each SMT pick and place machine is guaranteed to boost your PCB assembly business thanks to the number of qualities listed below.

  • ⚡Precise Placement: The accuracy of our SMT pick and place machines can achieve a level of precision that surpasses any human pick and place handling.
  • 🔥High Flexibility: All SMT pick and place machines are easy to program for various PCB boards with different dimensions, production requirements, and specifications.
  • 🧱Ease of Use: With the user-friendly aspect of our SMT pick and place machines, they can be incorporated into your production floor with the minimum training requirement.
  • 🧩Low Maintenance: The cutting-edge technology of our SMT pick and place machines requires minimal maintenance, helping you reduce cost while increasing productivity.

🔶 Samsung SM421S High-Speed Chip Mounter Specifications

Model Samsung SM421S
Alignment Flying Vision + Stage Vision;
Number of Spindles 6 Spindles x 1 Gantry;
Placement
Rate		 Flying Vision Chip 1608 21,000 CPH (IPC9850)
SOP 15,000 CPH (IPC9850)
QFP 5,500 CPH (IPC9850)
Stage Vision 1.4sec / QFP 208 (Tray Supply Standard)
Placement Accuracy Chip / QFP ±50 @ µ+3s/ Chip,
±30 @ µ+3s/ QFP;
Component
Range		 Flying Vision 0603 ~ □22mm IC
Standard Stage
Vision (FOV45)		 □42mm IC (Lead Pitch 0.4mm) — □55mm (MFOV)
Optional Stage
Vision (FOV35)		 □32mm IC (Lead Pitch 0.3mm) — □55mm (MFOV)
Max. Height Flying Camera
Standard		 12mm
Stage Camera
Standard		 15mm
Board Size 50(L) x 40(W) — 460(L) x 400(W)mm;
PCB Thickness 0.38mm ~ 4.2mm;
Feeder Capacity 60ea ( Front and rear fixed feeder band);
Utility Power AC200 / 208 / 220 / 240 / 380 / 415 V
(50/60Hz, 3Phase), RMS 3kVA (Max. 4.7kVA);
Air Consumption 0.5 ~ 0.7MPa(5.1 ~ 7.1kgf/cm2), 260N/min;
Weight 1800Kg;
External Dimension 1650(L) x 1690(D) x 1535(H)mm.
