Outstanding Products Make You Stand Out
Each SMT pick and place machine is guaranteed to boost your PCB assembly business thanks to the number of qualities listed below.
- ⚡Precise Placement: The accuracy of our SMT pick and place machines can achieve a level of precision that surpasses any human pick and place handling.
- 🔥High Flexibility: All SMT pick and place machines are easy to program for various PCB boards with different dimensions, production requirements, and specifications.
- 🧱Ease of Use: With the user-friendly aspect of our SMT pick and place machines, they can be incorporated into your production floor with the minimum training requirement.
- 🧩Low Maintenance: The cutting-edge technology of our SMT pick and place machines requires minimal maintenance, helping you reduce cost while increasing productivity.
🔶 V450T Fully Automatic PCB Laser Marking System Specifications
| Item | Technical Parameters |
| Laser Type | UV Laser, Green Laser, Fiber Laser, CO2 Laser (Optional) |
| Marking Area | 50*50mm – 3200*400mm (Depends on laser type and lens type) |
| Marking Speed | Up to 7000mm/s (Actual processing efficiency depends on laser type and power) |
| Marking Accuracy | ±0.05mm (Special requirements: ±0.03mm) |
| PCB Dimensions | L400mm × W320mm; Thickness 0.5mm-6mm (Adjustable for special requirements) |
| PCB Top Surface Height | < 37mm (Adjustable for special requirements) |
| PCB Bottom Surface Height | < 37mm (Adjustable for special requirements) |
| Applicable Products | PCB hard board with white, green, blue, and other inks; Copper, aluminum, etc. |
| Positioning System | CCD + MARK Point Positioning |
| Working Method | Two independent Laser XY movement modules (top and bottom) |
| 1D Barcode Types | Code 39, Code 25, Code 93, Code 128, EAN-13, EAN-8, ISBN, etc. |
| 2D Barcode Types | Datamatrix, QR Code, micro QR Code, PDF417, Code 49, Code 16K, etc. |
| 2D Barcode Size | 1.5mm×1.5mm ~ 20mm×20mm (Minimum size depends on laser type) |
| Character Types | Supports TrueType, JSF, SHX, DMF fonts |
| Minimum Character Height | 0.1mm ~ 0.4mm (Depends on laser type) |
| Supported File Formats | DXF, PLT, Excel, TXT |
| Positioning Function | Supports automatic imaging; 2-point, 3-point, and 4-point positioning methods |
| Code Reading Function | Automatically reads 2D barcodes and saves data; logs and alarms if reading fails |
| System Integration | Customizable interconnection with ERP/MES/SAP systems to automatically obtain work order number, batch number, material code, specifications, etc., for automatic marking |
| Conveyor Belt Width | Automatically adjusts according to PCB width |
| Power Supply | 220V/50Hz, Total Power ≈ 2500W |
| Air Pressure | 0.5 ~ 0.6 MPA |
| Dimensions (W*L*H) | 1050mm * 1470mm * 1450mm |
| Weight | 1000 KG |
