Outstanding Products Make You Stand Out
Each SMT pick and place machine is guaranteed to boost your PCB assembly business thanks to the number of qualities listed below.
- ⚡Precise Placement: The accuracy of our SMT pick and place machines can achieve a level of precision that surpasses any human pick and place handling.
- 🔥High Flexibility: All SMT pick and place machines are easy to program for various PCB boards with different dimensions, production requirements, and specifications.
- 🧱Ease of Use: With the user-friendly aspect of our SMT pick and place machines, they can be incorporated into your production floor with the minimum training requirement.
- 🧩Low Maintenance: The cutting-edge technology of our SMT pick and place machines requires minimal maintenance, helping you reduce cost while increasing productivity.
Equipment Features
Designed for the end of SMT production lines to automatically collect multiple-side PCBs. Upon receiving a board release signal from the host system, the machine picks up PCBs one by one and pushes them into magazines for storage.
-
Control System: PLC with color touch screen and tri-color LED indicator.
-
Magazine Capacity: Supports up to three magazines in rotation for continuous operation.
-
Special Circuit Design: Prevents PCB damage during pushing and handling.
-
SMEMA Standard Interface: 4-pin signal line for direct connection with other SMT equipment.
-
Black Board Detection: Optional.
Technical Specifications
-
Machine Dimensions: 1730 (L) × 765 (W) × 1270 (H) mm
-
PCB Size Range: 50 × 50 mm ~ 330 × 250 mm
-
PCB Handling Time: 6.0 sec per board
-
Working Height: 920 ± 30 mm (standard)
-
Power Supply: AC 220V ±10%, 50/60 Hz
-
Compressed Air Supply: 4–6 bar
-
Minimum PCB Thickness: 0.4 mm
-
Pitch Selection: 10 / 20 / 30 / 40 mm (selectable)
Note: Magazines not included.
